ATAL 300NC, ATAL 430A, and ATAL 530A

ATAL 300NC, ATAL 430A, and ATAL 530A

ATAL 300NC, ATAL 430A, and ATAL 530A are high-performance Double Column High Speed Fully-Automatic Band Saw Machines designed for precise and heavy-duty industrial cutting applications. These machines are ideal for cutting solid bars, structural materials, and large metal workpieces with excellent accuracy and stability. Built with a strong double-column structure, they ensure vibration-free operation and long-term reliable performance in demanding industrial environments. Their fully automatic working system improves production speed, reduces manual effort, and delivers consistent cutting quality for continuous operations. Equipped with hydraulic blade tension, VFD blade speed control, and advanced material feeding systems, they provide smooth and efficient cutting performance. These machines are perfect for steel industries, fabrication units, engineering workshops, and large-scale manufacturing plants requiring powerful and precise cutting solutions.

Category:

Reviews

There are no reviews yet.

Be the first to review “ATAL 300NC, ATAL 430A, and ATAL 530A”

Your email address will not be published. Required fields are marked *

Description

Technical Parameters ATAL 300NC ATAL 430A ATAL 530A
Cutting Cap. Round 300 mm 430 mm 530 mm
Cutting Cap. Square 300 x 300 mm 430 x 430 mm 530 x 530 mm
Bundle Cutting Size 300 x 160 mm 400 x 200 mm 500 x 200 mm
Blade Size 4115 x 34 x 1.1 mm 5100 x 41 x 1.3 mm 6350 x 41 x 1.3 mm
Blade Speed (VFD) 15 to 80 m/min 15 to 80 m/min 15 to 80 m/min
Saw Motor 5 HP (3.75 kW) 7 HP (5.5 kW) 10 HP (7.5 kW)
Hydraulic Motor 2 HP (1.5 kW) 2 HP (1.5 kW) 2 HP (1.5 kW)
Coolant Pump 0.18 HP 0.18 HP 0.18 HP
Hydraulic Tank 60 Liter 60 Liter 60 Liter
Coolant Tank 80 Liter 80 Liter 100 Liter
Multiple Feed Stock 500 mm x 9 times 500 mm x 9 times 500 mm x 9 times
Machine Weight 2100 KG 3200 KG 4500 KG
Machine Dimension 2350 x 2350 x 1520 mm 2600 x 2450 x 1750 mm 3150 x 2560 x 2100 mm

Advance Features

  • Auto shut off in case of Blade breakage or slippage
  • Safety Interlock Door
  • Automatic Chip Brush
  • Working Light
  • Split Cutting Vice
  • NC Control
  • Saw Frame Height Selector Gauge
  • Material Detection Device
  • Chip Collection Basket
  • Automatic Chip Conveyor
  • Hydraulic Blade Tension
  • Top Clamping Arrangement
